JD-AB500 Gravity Die Casting Machine.
It's a machine which used in casting not only copper but also brass. And the main point, they can't used in aluminum and zinc. If you want cast zinc or aluminum, please choose our products JD-650-75A or JD-750-75A
Maximum Outlined Diameter of Mold 500mm
Maximum Weight of Mold 150kg
Maximum distance of mold base plate 510mm
Maximum clamping stroke 270mm
Angle range of measured-cast 0° -90°
Angle range of mold immersion 0° -110°
Angle range of mold immersion 0° -90°
Oil Pressure 50-70bar
Power capacity 3.75+0.75+0.75W
Three phase power 380V/50Hz(per customers requirement)
Oil tank capacity 220L
Volume of mold immersion tank 375L+375L
Net weight of the Equipment 2000kg
Maximum dimension of the equipment 1650*2300*1720mm
| Maximum Outlined Diameter of Mold | 500mm |
| Maximum Weight of Mold | 150kg |
| Maximum distance of mold base plate | 510mm |
| Maximum clamping stroke | 270mm |
| Angle range of measured-cast | 0° -90° |
| Angle range of mold immersion | 0° -110° |
| Angle range of mold immersion | 0° -90° |
| Oil Pressure | 50-70bar |
| Power capacity | 3.75+0.75+0.75w |
| Three phase power | 380V/50HZ(per customers requirement) |
| Oil tank capacity | 220L |
| Volume of mold immersion tank | 375L+375L |
| Net weight of the Equipment | 2000kg |
| Maximum dimension of the equipment | 1650*2300*1720mm |
"Jingda Machinery" is the brand of Quanzhou Jinglong Machinery Company. We are a complete sets of sanitary plumbing equipments manufacture specially in technical process guidance, mold designing, on-site staff training services.
Main products: Gravity Casting Machine, Double Automatic Core Shooting Machine, Vertical Core Shooting Machine, Sand Mixing Machine, Biaxial Composite Machine, Low Pressure Casting Machine, Zinc Alloy Casting Machine, Pneumatic Clamps, Surface Lapping Machine etc.
We offer free professional technician training service to help technicians in well mastering the equipment operation and achieving the expectation.
We always abode by its principle of "the quality of survival, technology for development". Through constantly creating, hard-working and innovation to create superior products, improve company's strength and perfect the market system. We are dedicated to provide customers with comprehensive after-sales services. We will hold hand by hand with all customers home and abroad to create more achievements with our best sincerity.
