Cold Work Tool Steel A6 with High Quality

Shape: Round, Flat, Square.

Size Range:

	Diameter(mm)	Thickness (mm)	Width (mm)	Length(mm)
Round	50-420	-	-	2000-5800
Square	50-420	-	-	2000-5800
flat	-	20-50	80-600	2000-5800


Steel-making Condition: EF, EF/EAF+LF+VD, EF/EAF+ESR,

Delivery Condition:
Annealed , Quenched + Tempered

Surface Condition:
Black, Grinded, Peeled, Rough turned, Polished

Features:
1.Competitive price
2.Immediate delivery
3.Premium quality
4.Reliable service
5.MOQ: 1 Ton

Packing details	In seaworthy packing, as your requirement.
Delivery details	within 30-50 days


Chemical Composition:

C	Mn	P	S	Si	Cr	Mo
0.65-0.75	1.80-2.50	0.030max	0.030max	0.10-0.70	0.90-1.40	0.90-1.40


Mechanical Properties:

Ultrasonic Test:Material will be ultrasonically tested at appropriate stages of the manufacture to ensure the quality, as agreed between seller and purchaser.

Heat treatment:
Forging: Heating for forging must be done slowly and uniformly. Soak through at 1900°-2000°F and reheat as often as necessary, stopping work when the temperature drops below 1600°F. After forging, cool slowly in lime, mica, dry ashes or furnace. A6 Tool Steel should always be annealed after forging.

Annealing: Heat slowly to 1350°-1375°F, hold until entire mass is heated through, and cool slowly in the furnace (20F per hour) to about 1000°F, after which cooling rate may be increased. Suitable precautions must be taken to prevent excessive carburization or decarburization.

Hardening: Parts at room temperature or as pre-heated should be placed in a hardening furnace operating at 1525°-1600°F. After parts have reached the furnace temperature, hold 20 minutes for small parts and up to 45 minutes for large parts.

Tempering: A single temper (one hour at temperature for small pieces; proportionately longer time for larger sizes) is usually all that is required with tempering carried out in the range of 300°-1000°F. For most applications, the best combination of hardness and toughness is accomplished at 350°-400°F. Specimens 1 inch square by 3 inches long were air hardened from 1550°F and tempered at various temperatures for two hours.

Application:
Typical applications for A6 Tool Steel are blanking dies, forming dies, trim dies, stamping dies, coining dies, notching dies, bending tools, rim rolls, punches, cams, thread roll dies, spindles, retaining rings, master hobs, precision tools, mandrels, compression molds, plastic molds requiring high hardness, ball screws, lead screws, general purpose tooling, etc.
