| Price: | US $ 88-100/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Paypal,Money Gram |
1.2344 Square Steel
1.steel with full size
2.payment:TT/LC at sight
3.best quality and service
4.16 years production experience
5.ISO9001-2008 certificated,PED SGS
1.2344 Square Steel Chemical composition:
Steel grade:DIN 1.2344
C:0.37-0.42
Si :0.90-1.20
Mn:0.30-0.50
P:<=0.030
S:<=0.030
Cr:4.80-5.50
Mo:1.20-1.50
V:0.90-1.10
Mechanical properties:
GB/T1299-2000 : <=235
DIN : <=235 Annealed(HB)
AISI:192-229 Annealed(HB)
Delivery condition:hot rolled,forged,annealed
| Wind Turbine Shaft | 42CrMo4, 34CrNiMo6 |
| Marine Shaft | C-Mn steel |
| Hydro Turbine Shaft | 20SiMn |
| Roller Shaft | 70Cr3Mo; 9Cr2Mo; MC1; MC2; MC3 |
| Gear Shaft | 17CrNiMo6; 18CrNiMo7-6; 20CrNi2Mo; 42CrMo; 47CrNiMo6, 20CrMnMo |
| Gear | 17CrNiMo6; 18CrNiMo7-6; 20CrNi2Mo; 42CrMo; 47CrNiMo6, 20CrMnMo, 30 CrNiMo6 |
| Pressure Vessel Forgings | SA105, SA350 LF2, 16Mn, 20MnMo, 15MnMo, 12Cr2Mo1, 14Cr1Mo, 42CrMo, F304, F316, 17-4PH, 4330, 4336, 4340 |
| Ring Rolling | 16Mn, 50Mn, 42CrMo, 15MnV, 35CrMo, A105, 20#, 304, 304L, 316, 316L |
Application:
1.2344 square steel
1.Hot-work tool steel for die casting tools,forming dies,die inserts,hot shear blades.
2.Highly stressed hot work tools.pressure casting dies and metal extrusion tools for processing light metal alloys,tools for the manufacture of hollows,tools for the screws manufacture,nuts,rivets and bolts.
3.Such as mandrels,dies and contaniners for metal tube and rod extrusion with very good thermal conductivity.
Size available:
Square /Round Bar :20-550mm
Flat:Min thickness,20mm;Max width,1000mm
Note:
1. According to national standard (GB)for our products, if not, supply according to national standards(GB) or agreement.
2. We can not only provide electric furnace +LF+VD and electroslag re-melting(ESR)steel forging materials, but also forging products of piece, bar, etc.
3. Our company is equipped with roll equipment and can provide our customers with roll billets or finished.
4. Please send us your detailed specifications when inquire.We will reply to you as soon as possible.
| Prod Model: | free size |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Many Size: | Big Size |
| Processing Object: | Metal |
| Molding Style: | Forging |
| Heat Treatment: | Accroding to Customer's Order |
| Surface Treatment: | Accroding to Customer's Order |
