Open side C type hydraulic press:
HPC series open side "C"type hydraulic press, with trihedral open worktable, suitable for assembling and dismantling complex structure and large volume parts.
HPC series open side "C"type hydraulic press, with trihedral open worktable, suitable for assembling and dismantling complex structure and large volume parts.1.Drived by hydraulic pressure generated by motor, adopts advanced dual oil cylinder and hydraulic circuit, causes low heat while operates at a speed of more than 150mm per second; 2.Hydraulic pressure actuation of 1-14MPA, three-phase alternating-current supply, AC380V 50HZ or AC220 60 HZ, total consumptions of electricity of less than 3.7KW 3.The frame adopts integrity welding technology with better regidity and stability of machine while wide convenient operation space; 4.Pressing force, stroke of cutting, dwell time, die height could be adjusted manually comply with pratical demand; 5.Intelligent functions: intellegent counter, force measurement monitor, intelligent temperature controler(Customized available)
MODEL |
HPC-20T |
HPC-30T |
HPC-50T |
HPC-63T |
HPC-100T |
CAPACITY(KN) |
200 |
300 |
500 |
630 |
1000 |
PRESSURE(MPa) |
25 |
25 |
31.5 |
31.5 |
31.5 |
TRAVEL (mm) |
300 |
300 |
300 |
300 |
400 |
TALE SIZE( mm) |
400*300 |
400*300 |
400*600 |
400*600 |
500*800 |
DIMENSION(mm) |
800*600*1500 |
800*600*1500 |
800*1200*1800 |
800*1200*1800 |
1000*1600*2100 |
WEITHT (KG) |
460 |
600 |
980 |
1150 |
1350 |
