Nominal diameter Coupled O.Dof pipes Diameter of inseting hotes Flange dimension Bolt holes
O.D Thickness Center distance Quantity Diameter
10A 17.3 17.8 90 12 65 4 15
15A 21.7 22.2 95 12 70 4 15
20A 27.2 27.7 100 14 75 4 15
25A 34.0 34.5 125
32A 42.7 43.2 135 16 100 4 19
40A 48.6 49.1 140 16 105 4 19
50A 60.5 61.1 155 16 120 4 12
65A 76.3 77.1 175 18 140 4 19
80A 89.1 90.0 185 18 150 8 19
100A 114.3 115.4 210 18 175 8 19
125A 139.8 141.2 250 20 210 8 23
150A 165.2 166.6 280 22 240 8 23
200A 216.3 218.0 330 22 290 12 23
Shijiazhuang Guangjin Valve Industry Co., Ltd is state-owned medium-sized township enterprise combining technological research, production, transportation and sales into one. In 1994, we established a Sino-South Korean joint venture. We have more than 30 freight trucks to make freight transport convenient. Our company specializes in producing all sorts of middle and low pressure cast iron, cast steel and stainless steel valve products. There are more than 50 series and 500 kind of specifications and our leading products include the gate valve, the butterfly valve, the stop valve, the ball valve, the check valve, and so on.
Our main products are Z44T/W-10 sluice valve, Z45T/W-10 sluice valve, Z41T/W-10 sluice valve, Z15T-16 sluice valve, J41T/W-16 stop valve, J41H-16 stop valve, J41F-16 stop valve, J41H-16 straight-through angle type stop valve, J41H-25 stop valve, J11T/X-16 stop valve, D71X-10 butterfly valve, D371X-16 butterfly valve, H41T/W-16 lift check valve and return box, H44T/WX-10 swing check valve, H42X-2. 5 lift bottom valve, Q41F-16 ball valve, Q11F-10 ball valve, G41H-16 filter valve, G11H-16 filter valve, Z44H-16 draw off valve, U41S-16 plunder valve, J24T-10 splayed valve, S49H-16 trap, S19H-16 trap, H12T-16 check valve, and Hj11T-16 check valve in more than 500 specifications in more than 50 series.
We will continue to provide higher quality and more competitive price to thank our customers' loyalty. And we will satisfy you in heat control and energy saving by using precise equipment, strict testing and advanced technological process. Your will feel satisfied after you visit our factory.
