Model | Theoretical displacement (mL/r) | Max pressure | Allowed driving speed (r /min) | Weight (kg) | |||||
| Working oil of Petroleum series | Water-based synthetic hydraulic fluid | ||||||||
| Particular pressure oil | Anti-wear oil | Common oil | Anti-wear water-glyco | Sul phosuccinic Ester fatty of acid | Max | Mini | |||
| PV2R1-6 PV2R1-8 PV2R1-10 PV2R1-12 PV2R1-14 PV2R1-17 PV2R1-19 PV2R1-23 PV2R1-25 PV2R1-28 PV2R1-31 | 6.1 8.1 10.2 12.3 14.0 16.3 18.3 22.5 25.1 27.6 30.6 | 21 | 17.5 | 16 | 16 | 16 | 1800 (1200) | 750 | 8 |
| PV2R2-26 PV2R2-33 PV2R2-41 Pv2R2-47 PV2R2-53 PV2R2-59 PV2R2-65 PV2R2-75* | 25.4 32.2 40.5 46.2 52.3 58.2 64.1 74.5 | 21 | 17.5 | 14 | 16 | 14 | 1800 (1200) | 600 | 16 |
| PV2R3-52 PV2R3-60 PV2R3-66 PV2R3-76 PV2R3-85 PV2R3-94 | 51.5 62.9 67.0 79.2 84.5 93.8 | 21 | 17.5 | 14 | 16 | 14 | 1800 (1200) | 600 | 32 |
| PV2R3-116 PV2R3-125 PV2R3-136 PV2R3-153 | 113.2 122.8 135.8 152.8 | 17.5 | 16 | 14 | 1200 | #34 | |||
| Prod Model: | PV2R1/PV2R2/PV2R3 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: | PV2r1/PV2r2/PV2r3 |
| Displacement: | Quantitative Pump |
| Nominal Displacement(Ml/R): | 6~153 |
| Mounting Type: | Flange Mounting |
| Shaft Extension: | Major Shaft Standard or Minor Shaft |
| Direction Of Rotation: | Right Rotation Standard or Left Rotation |
| Inlet Position: | Upper(Standard)/Bottom/Right/Left |
| Allowed Driving Speed(R /Min): | 1800(1200)-600 |
| Usage: | Hydraulic Oil |
| Warranty: | One Year |
| Mesh Form: | External Engaged |
| Tooth Flank: | Skew Tooth |
| Tooth Curve: | Cycloid |
| Power: | Hydraulic |
| Type: | Vane Pump |
