HPB series hydraulic press is used fro assembling, dismantling, alignment, calendaring, tension, bending and punching. The machine supplied oil by Italy CNK and CBZ pump. It could save 60% energy compared with the traditional model. The efficiency increased to 2-3 times. It takes the advantages of small volume, high pressure, simple structure and light weight.
- strong hydraulic cylinder and two circular guides ensure uniform and precise feeding during press operation
- also suitable as try-out press
- ram plate and large work table with T-slots for tool clamping
- firmly bolted work table
- adjustable end stop
· Dealing directly with the manufacture- no middle man!
· The most competitive pricing in the market.
· High quality control standards, such as ISO, CE
· Guaranteed delivery time.
· Prompt attention to the customer inquiries.
· Diverse services for your needs, including sourcing other machinery, inspection goods for you by our engineers, product process tracking and good delivery.
· Research and Development to meet the customer and the market need.
| model | units | HPB-20 | HPB-30 | HPB-50 | HPB-63 | HPB-100 | HPB-150 | HPB-200 | HPB-300 |
| capacity | kn | 200 | 300 | 500 | 630 | 1000 | 1500 | 2000 | 3000 |
| pressure | Mpa | 25 | 25 | 25 | 30 | 30 | 30 | 30 | 30 |
| travel | mm | 200+270 | 300+270 | 220+405 | 220+405 | 250+405 | 250+405 | 300+405 | 300+405 |
| Table size | mm | 200*360 | 300*400 | 400*800 | 400*800 | 460*980 | 460*980 | 500*1000 | 700*1200 |
| dimension | mm | 1060*500*1400 | 1160*550*1600 | 1500*650*1950 | 1500*650*1950 | 1730*730*2250
730*630*960 | 1730*730*2250
730*630*960 | 1940*950*2350
900*800*1060 | 2100*950*2700
1100*1200*1350 |
| weight | kg | 550 | 650 | 1100 | 1200 | 1420 | 1750 | 2400 | 4200 |
The main products include machine tools like Plano Miller/Plano Milling Machine/Gantry Milling Machine/Planer Milling machine, Conventional Milling Machine & Milling/Drilling Machine, Vertical Lathe, Horizontal Lathe, Radial Drilling Machine, Vertical Drilling Machine, Gear Shaper & Hydraulic Shaper, Press, Shearing Machine, Press Brake, Saw Machine, Riveting Machine, Air Hammer, etc; Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal Boring Head, Clamp kits, etc. And the other product range is garage equipments like Cylinder(Blocks) Boring Machine/Fine Boring Machine, Cylinder Honing Machine, Brake Drum Boring Machine, Brake Lathe/Brake Drum(Disc) Cutting Machine, etc.
All of them have adopted modernized ISO Quality Management System, sound operational procedures as well as effective service system. All the commodities are carefully produced and we bear in mind that products with consistent good quality are crucial to the ongoing success of your operations.
