We are one of the Chinese professional manufacturers work at different types of Nail Making Machines. The following items are the related products of the Nail Making Machines, kindly pls view the details as follow. If any query you have for Nail Making Machines, pls don't hesitate to contact with us at any time and we are willing to further assist you!
Description:
Low noise
High speed
High quality
Nail making machine
This new type machine adopts plunger and oil pipe lubricating structure so as to ensure the features such as high speed, low noise and less impact. Especially, it can make high quality of asphalt felt nails and other special nails used for high speed coil collator and coil nails.
The maintain of nail making machine
1, No adjust when the machine is working
2, Keep the machine clear, wash the nail mould regularly, don't use rust the steel wire making nail.
3, before pull the inlet wire hand shank, the nail machine should be open in advance. Stop inlet wire when you want to turn off the nail machine.
4, keep the nail knife sharp.
5, Note the temperature changes of each rub parts and abnormal noise in the machine running.
6, Turn off the powder supply before you fix the machine.
7, Use original specification when you need change some equipment parts.
8, lubrication the machine regular, when use a new machine, it should be lubricated mass in 15 days.
9, Don't running the machine after dismantle the protective cover.
|
Model: |
Unit |
Z94-5C |
Z94-4C |
Z94-3C |
Z94-2C |
Z94-1C |
|
Dia of nail max: |
mm |
6 |
4.5 |
3.1 |
2.8 |
1.6 |
|
Dia of nail min: |
mm |
2.5 |
2.8 |
1.8 |
1.2 |
0.9 |
|
Length of nail max: |
mm |
150 |
100 |
75 |
50 |
25 |
|
Length of nail min: |
mm |
50 |
50 |
30 |
16 |
9 |
|
Designed output: |
Pcs/min |
180 |
260 |
280 |
300 |
450 |
|
Motor power: |
kw |
5.5 |
4 |
3 |
2.2 |
1.5 |
|
Weight: |
kgs |
2500 |
2000 |
1800 |
1500 |
1200 |
|
Overall dimensions: |
mm |
2600*1650*1750 |
2200*1600*1650 |
2000*1400*1400 |
1700*1300*1400 |
1500*1300*1200 |
