Aluminum Rod Continuous Casting and Rolling Line
| Price: |
US $ 350000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,D/P,Western Union |
1. Brief introduction
Aluminum rod continuous casting and rolling line can produce three kinds of conductive aluminum rods of 15mm, 12mm, 9.5mm.
15mm aluminum rod is produced by 10 rolling stands;
12mm aluminum rod is produced by 12 rolling stands;
9.5mm aluminum rod is produced by 14 rolling stands.
2. Process Flow
2.1 Aluminum ingot and scrap aluminum wire-alumInum melting furnace --four-wheel horizontal continuous casting machine- oil-pressure shearer -continuous rolling mill - coiler with dual basket - aluminum rod
2.2. Melt aluminum or melt aluminum molten which is stored in the holding furnace will be injected to four-wheel continuous casting machine through launders. The sectional area of trapezoidal casting ingot is2, 330mm² , Scrap aluminum bar is cut by oil-pressure shearer and then acceptable aluminum bars are sent to continuous rolling mill, after emulsion bag, guiding wheel, leading pipe and take-up coiler, the rod will become looping.
3. Main Technical Parameters
| NO. | Technical parameter | Date |
| 1 | Diameter (finished EC-aluminum) | 9.5, 12, 15mm |
| 2 | Max. Capacity | 6t/h |
| 3 | Coil's weight | ~2t |
| 4 | Overall weight of main equipment | ~ 65t |
| 5 | Overall power of main equipment | ~470kW (excluding furnace) |
| 6 | Finished rolling speed | ≤ 8.17m/s |
| 7 | Overall dimension: Approx. | 32.1× 7.2× 4.2m (L × W × H) |
4. Supply of scope
4.1. Four-wheel Continuous Casting Machine (with 2PCS of casting ladles)
4.2. Single-Track Oil Hydraulic Shearer
4.3. Continuous Rolling Mill
4.4. Emulsion Lubrication System for Rolling Mill
4.5. Lubrication System for Gearbox
4.6. Emulsion bag, Guiding wheel and Leading Pipe
4.7. Coiler and Coiler with Dual Basket Trolley
4.8. Electrical Control Device
| Prod Model: |
SH1600/9.5(12, 15)-255/14 (12, 10) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Blue |
| Certification: |
CE |
Chengdu Shuhong Equipment Manufacturing Co., Ltd (formerly Chengdu Shuhong
Machinery Corp., Ltd). is located in Qingbaijiang district of Chengdu, the beautifulland of abundance. The garden company was established in 1996, which is a self-R-D, manufacturing and mechatronics economic entity. The factory covers an area of 120, 000m2 with production workshops about 50, 000 m2. It owns various types of machining equipments, including floor-type CNC boring machine, vertical lathe, mill machine, planer, grinding machine, wire-electrode cutting, etc., lifting equipment such as 60T cranes, welding equipments, non-destructive testing equipments, and precision forging equipments.
Including: Two workshops 28313.10 m2
Office building 9479.50 m2
Stated Technology Center 4537.80 m2
Our company focuses on wire and cable equipments research and innovation, and becoming the leader of advanced technology in the industrialincreasingly. Depends on innovative technology, excellent products quality and thoughtful after-sales service, the copper/aluminum (alloy) rod CCR line with refining melting furnaces designed by Chengdu Shuhong have occupied about 80% domestic marketing share, products in the same industry in the country, even the first year sales. In the meanwhile, the products also have been exported to more than 20 countries and areas, including USA, Mexico, Turkey, India, Indonesia, Malaysia, Iran, Iraq, Syria, Algeria, Egypt, and Kazakhstan, etc., Chengdu Shuhong is a trusted partner for customers at home and abroad.
With years of rich service experience in the wire and cable industry, Chengdu Shuhong intakes the advanced technology from both domestic and overseas constantly, and has developed a series of new products to meet the full customer demand for unique personalized, such as: wheeL-belt type aluminum alloy ingot casting production line, 40-48t/h copper rod continuous casting and rolling line, 8t/h aluminum alloy continuous casting and rolling line, etc. The company has developed and produced of a grand total of more than 20 types products, including: non-ferrous metal rolling equipment, power cable equipment, submarine cable equipment, ferrous metal rolling equipment, environmental protection equipment, pressure vessel and so on. Chengdu Shuhong has got nearly 20 national patents and established the ISO9001: 2008 quality management system. ''SHUHONG'' is the provincial and municipal famous brand, China famous brand, and the main product has been promoted to be quality reliable products by China Electrical Equipment Industry Association.
Nowadays, Chengdu Shuhong has made great progress, and adhering to the concept of ''Innovation, professional manufacture, sincere service'', Chengdu Shuhong with full''enthusiasm and moving toward with a goal of becoming the world- leading electrical ''equipment manufacture. ''The chairman of company, Mr. Huang Hechang would like to invite all friends of different ''fields at home and abroad to our company, beautiful Chengdu city, and seek for mutual cooperation and together development.
