Description and Applications
1) 3W/4W/5W/7W Hi Power epistar LEDs.
2) 45 Degree Beam Angle
3) Input Voltage 85-265V, Dimmable version available
4) Replace for 35W/50W halogen lamp
5) Conductive Die-casting Aluminum(Private mold, Philips like) heat sink.
6) Application: Coffee bar, Hotel, Home, Public place etc
7) Warranty: 2 years
|
| LED Spec | Holder | Input Voltage | Colour | CCT | CRI | Lumen | Dim/Non-Dim |
| 3W Hi Power CW | GU10 | AC85-265V | Cool White | 5500-6000K | CRI>80 | 250LM | Available |
| 3W Hi Power WW | GU10 | AC85-266V | Warm White | 2700-3500K | CRI>80 | 280LM | Available |
| 4W Hi Power CW | GU10 | AC85-265V | Cool White | 5500-6000K | CRI>80 | 320LM | Available |
| 4W Hi Power WW | GU10 | AC85-266V | Warm White | 2700-3500K | CRI>80 | 350LM | Available |
| 5W Hi Power CW | GU10 | AC85-265V | Cool White | 5500-6000K | CRI>80 | 410LM | Available |
| 5W Hi Power WW | GU10 | AC85-266V | Warm White | 2700-3500K | CRI>80 | 380LM | Available |
| 7W Hi Power CW | GU10 | AC85-266V | Cool White | 5500-6000K | CRI>80 | 500LM | Available |
| 7W Hi Power WW | GU10 | AC85-267V | Warm White | 2700-3500K | CRI>80 | 460LM | Available |
| Enviroment Parameters |
| Operating Temperature | -20Celsuis ~ +50Celsuis |
| Storage Temperature | -40Celsuis ~ +80Celsuis |
| IP Rating | IP33 |
| PACKING DETAILS |
| Item N.W. | Item G.W. | Box Size (mm) | PCS/Mid Box | PCS/CTN | CTN Size(cm) | N.W.(KG) | G.W.(KG) |
| 45g | 55g | 52*52*63 | 20 | 100 | 58*28.5*16 | 6 | 7
|
EcoledEnergy is a skilled manufacturer and knowledgeable exporter for LED light source, and with nearly five years experience in export business, we have grown into a high efficient team to serve and provide our customers with an extensive range selection of high quality lighting fixtures at competitive prices.
We are production and exporting LED bulb, LED spot light, LED Tube, LED Strips, G4lamps, G9 lams, LED downlight, etc. Our market covers all over the world, including USA, Canada, UK, Mexico, Brazil, Argentina, Chile, Panama, Germany, France, Spain, Netherlands, Italy, Poland, Russia, Australia, New Zealand, Japan, Korea, Thailand, Malaysia and Indonesia, etc.
Working to meet our corporate aim of "good quality and service, mutually beneficial cooperation", we are also committed to continually introducing new technologies into our manufacturing processes. If you are interested in experiencing our services for yourself, or wish to receive any more information, please don' T hesitate to contact us.
We hope to establish and maintain a long-term successful alliance with you in the near future.
Hope our lamps can set your life bright.
