55kg Power Die Air Forging Hammer with CE Approved

55kg Power Die Air Forging Hammer with CE Approved
Price: US $ 1/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
C41-55  55kg Power Die Air Forging Hammer with CE Approved
Main Features

The air hammer with small size,low noise,simple structure ,
easy operation ,flexible movement and convenient to transit ,
installation ,maintenance ,the type is widely used for various of free forging works ,
such as drawingout ,upsetting ,punching ,chiseling .forging welding ,bending and twisting .
It is also used for opendie forging in bolster dies.
it is suitable for free forging works of all kinds of different shape parts ,
especially suitable for village township enterprise and selfemployed forge small agriculture tools .
For example sickle ,horseshoes ,Spike ,hoe etc .
At the same time ,the industrial enterprise use the air hammer to forge the steel ball ,
scaffold and many other factories and mines ,construction supplies .
In addition the series air  hammer is very commonly professional blacksmith's iron tools
that can install all kinds of mould to forge a variety iron flowers ,birds and other beautiful decoration.

Specifications
1.Durable and great power
2.Easy installation and operation
3.Convenient maintenance
4.Professional hammer die upon your need
SPECIFICATIONUNITC41-40kgC41-55kgC41-75kgC41-150kg
separate/singleseparateseparateseparate
Max.   hit  energykj0.53
0.7
12.2
Height  of  working  areamm245265300370
Hit  number min -1245230210180
Dimension of top and bottom die surface(LxW)mm120*50 120*55  145*65200*85
Max.   square  steel  can  be  forgedmm52*5252*5265*65130*130
Max.   round  steel  can  be  forged(Diameter)mm¢68¢68¢85¢145
Motor    powerkw45.57.515
Speeds  of  motorr. p. m1440144014401470
Anvil  weightkg400/06008501800
Total  weightkg1350/880170028005060
Overall  dimensions(L*W*H)mm1080*600*14301320*670*1620 1400*760*19502080*1240*2350
Prod Model: C41-55
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: C41-40,C41-55,C41-75,C41-150
Forging Forming Method: Mold Forging
