Medium Frequency melting Electrical Oven is for melting cast steel, cast iron, stainless steel, copper, aluminum and other metals or its alloy. It can also be used together with self-heated furnaces and electric arc furnace for heating or keeping warm/holding the molten iron and molten steel.
It is particularly suited to small and medium-size enterprises, or as Precision Casting Material Test.
@ Electrical Feature:
1. Digital CMOS chip (U. S. ASIC-2-12), with the highest degree of integration at home, is used in control circuit, the overall machine controlled through one single panel;
2. Frequency-sweep zero voltage start, high success rate, no shock;
3. Automatic resistance adjustment, permanent power output, 10-20% energy saved in comparison with domestic traditional machine of the type;
4. Auto phase sequence adaptation, free of synchronization;
5. Good performance in reload staring, auto recovery;
6. Highly integrated in controlling circuit, free of use of high-rate starter and relay loop, fairly low failure rate;
7. Wholly digital design, strong in anti-interference, no temperature shift when in continuous working;
8. Multi-protection functions (for over current, over voltage, insufficient water pressure, power failure, or phase absence), and mishandling will not cause damage to machine.
| Kw | V | A | Kw | A | V | T/H | Hz | V | T | KWH/T |
| GW-0.01-50/1JJ | 60 | 380 | 76 | 50 | 140 | 400 | 0.06 | 1000 | 750 | 0.01 | 850 |
| GW-0.03-100/1JJ | 100 | 380 | 160 | 100 | 200 | 500 | 0.09 | 1000 | 750 | 0.03 | 850 |
| GW-0.05-100/1JJ | 100 | 380 | 160 | 100 | 200 | 500 | 0.12 | 1000 | 750 | 0.05 | 800 |
| GW-0.08-100/1JJ | 100 | 380 | 160 | 100 | 200 | 500 | 0.12 | 1000 | 750 | 0.08 | 800 |
| GW-0.15-100/1JJ | 100 | 380 | 160 | 100 | 200 | 500 | 0.15 | 1000 | 750 | 0.15 | 820 |
| GW-0.25-160/1JJ | 180 | 380 | 256 | 160 | 320 | 500 | 0.24 | 1000 | 750 | 0.25 | 790 |
| GW-0.5-250/1JJ | 280 | 380 | 400 | 250 | 500 | 500 | 0.4 | 1000 | 1500 | 0.5 | 770 |
| GW-0.75-400/1JJ | 400 | 380 | 650 | 400 | 800 | 500 | 0.6 | 1000 | 1500 | 0.75 | 770 |
| GW-1-500/1JJ | 550 | 380 | 800 | 500 | 1000 | 500 | 0.8 | 1000 | 1500 | 1 | 750 |
| GW-1-750/1JJ | 800 | 380 | 1200 | 750 | 1500 | 500 | 0.9 | 1000 | 1500 | 1 | 720/660 |
| 690 | 700 | 850 | 880 | 500 | 2600 |
| GW-1.5-1000/0.5JJ | 1100 | 690 | 912 | 1000 | 1140 | 880 | 1.2 | 500 | 2600 | 1.5 | 700 |
| GW-2-1500/0.5JJ | 1650 | 690 | 1360 | 1500 | 1700 | 880 | 1.7 | 500 | 2600 | 2 | 675 |
| GW-2-2000/0.5JJ | 2200 | 690 | 1400 | 2000 | 2275 | 880 | 1.9 | 500 | 2600 | 2 | 650 |
| GW-3-2500/0.5JJ | 2750 | 690 | 2275 | 2500 | 2840 | 880 | 2.56 | 500 | 2600 | 3 | 610/560 |
| 950 | 1700 | 2080 | 1250 | 3200 |
| GW-5-4000/0.5JJ | 4400 | 690 | 2300 | 4000 | 4540 | 880 | 4.5 | 500 | 2600 | 5 |
