1. Diameter: 4-30mm,
2. Length: 10-300mm
3. Three Station, Four Station, Five Station
1, cold heading is mainly used to produce bolts, nuts, nails, rivets steel ball and spare parts. A continuous, progressive, automation production.
2, A kind of special material can be copper, aluminum, carbon steel, alloy steel, stainless steel, titanium alloy, material utilization rate.
3, according to metal plastic deformation theory, the blank of metal under normal temperature, put some pressure, make in the mold cavity produce plastic deformation, according to the rules of shapes and sizes to shape.
4, cold heading bolt, nut molding machinery have many types, multiple series of model. Equipment reliable performance, high efficiency, stable product quality.
5, have a good surface quality and the size of the higher accuracy. In upset forging process because there are cold hardening, deformation is not big. Reduce craze.
6, cold dui scope in batch process, all kinds of specifications of the products, can reduce the cost.
7 nice cold pressing molding machine, compact structure, convenient operation, the processing precision. Widely used car, bicycle chain fasteners industry, especially applicable to the manufacture of various types of complex, profiled the standard parts. Can use directly offer yuan wire, a progressive shaping.
8, multistage cold dui machine adopts automatic cycle lubrication system products processing materials, high efficiency, high accuracy, good strength, improving power, and to increase the enterprise efficiency.
SPECIFICATION MODEL |
STBF |
STBF |
STBF |
STBF |
STBF |
STBF |
STBF |
10B4S |
13B4S |
17B4S |
19B4S |
24B4S |
30B4S |
36B4S |
FORGING STATION |
4 |
MAX. CUT-OFF DIA. (mm) |
8 |
10 |
12 |
15 |
18 |
23 |
29 |
MAX. CUT-OUT LENGTH (mm) |
70 |
105 |
135 |
140 |
185 |
270 |
290 |
MAX. KICK-OUT LENGTH (mm) |
60 |
90 |
115 |
120 |
185 |
230 |
235 |
MAX. P. K. O. LENGTH (mm) |
13 |
20 |
20 |
26 |
33 |
35 |
35 |
RAM STROKE (mm) |
120 |
150 |
180 |
200 |
280 |
360 |
360 |
FORGING POWER (ton) |
40 |
65 |
85 |
120 |
200 |
265 |
360 |
PRODUCTS |
SIZE |
1/4(m6) |
5/16(m8) |
3/8(m10) |
1/2(m12) |
5/8(m16) |
3/4(m20) |
1(m24) |
MAX. LENGTH (mm) |
50 |
75 |
100 |
100 |
150 |
200 |
200 |
MIN. LENGTH (mm) |
12 |
16 |
16 |
20 |
25 |
40 |
60 |
MAX. OUTPUT (pcs/minute) |
300 |
240 |
200 |
170 |
120 |
90 |
70 |
MAIN MOTOR (HP) |
15 |
20 |
30 |
50 |
75 |
100 |
125 |
APPROX. WT. (ton) |
7.5 |
12 |
17.5 |
23 |
43 |
65 |
90 |
ZheJiang ShengTuo Machinery Co., Ltd. is specialized in producing multi-station cold heading machine/bolt former, was founded in 2006, the total area is 17600 square meters, has dozens of engineers and technicians and they have a long time in this field, we have practical experience, advanced technology, well-equipped, and complete product line, Characterized with high production efficiency, long durability performance, easy adjustment and maintenance and outstanding cost effectiveness, "Shengtuo Machinery" is well suitable to the production of fasteners used for wide civil and industrial applications including automotive, aviation and electronic etc. Industries and becomes one of the most renewed brands in the world. Those make machine's pass rates reach 100%.
The company has passed ISO9001 and CE certifications, it is one of the most professional manufacturer of Multi-station cold heading machines in China, and most of the machines exported all over the world. High quality and reasonable price and best after sales service. We look forward to cooperating with you.
